Internal R Milling Cutter for Precision Corner Radius Machining

An internal R milling cutter, also known as a corner radius end mill, is a cutting tool designed to machine internal corners with a defined radius.

Unlike standard square end mills that create sharp 90° corners, internal R cutters produce rounded corners, which help reduce stress concentration and improve the strength of the workpiece.

This type of tool is widely used in mold making, precision machining, and structural component manufacturing where durability and surface quality are important.

                                                                     Technical Specifications

Our internal R milling cutters are manufactured with high precision to ensure consistent performance.

We support full customization based on your requirements, including radius size, geometry, and coating.

Our internal R milling cutters are designed to improve machining performance and workpiece quality.

The rounded corner design reduces stress concentration and improves part strength compared to sharp corners. High-quality carbide material ensures excellent wear resistance and long tool life.

Advanced edge preparation technology reduces micro-chipping and improves cutting stability. Precision CNC grinding ensures consistent geometry and smooth cutting performance.

These advantages make our tools ideal for mold and high-precision machining applications.

Internal R milling cutters are commonly used in applications that require smooth corner transitions and high structural strength.

They are widely used in mold and die manufacturing, where internal corners must have specific radii for better material flow and durability. These tools are also used in aerospace and automotive parts to improve fatigue resistance.

Typical applications include mold cavity machining, corner finishing, and precision part machining.

1. 20 Years of Manufacturing Experience

Dohre CNC Tools has more than 20 years of experience in manufacturing and supplying carbide cutting tools to global customers.

Over the past 20 years, we have continuously improved our production processes, quality control systems, and machining solutions to meet the evolving demands of modern precision manufacturing.

2. Advanced Production Equipments

All carbide cutting tools are manufactured using German Walter five-axis high-precision CNC grinding machines, ensuring exceptional accuracy and cutting performance.

This advanced equipment enables us to achieve:

•Extremely sharp cutting edges

•High dimensional precision

•Stable tool geometry

•Smooth and efficient cutting performance

These capabilities allow our tools to deliver consistent results in demanding machining environments.

3. Precision Inspection System

To ensure stable and reliable quality, every cutting tool undergoes strict inspection procedures.

Our inspection equipment includes:

•Walter Helicheck Plus profile measuring system from Germany

•150× optical measurement system for contour inspection

•300× high-definition visual inspection equipment for surface quality verification

These advanced inspection systems guarantee accurate geometry and consistent product quality.

4. Professional Engineering & Design Team

Our company is supported by an experienced engineering and design team specializing in carbide cutting tool development.

Based on different machining requirements, our engineers can provide:

•Custom cutting tool design

•Application optimization solutions

•Professional technical support

This allows us to provide reliable OEM and non-standard cutting tool solutions for various industries.

5. Global Market Presence

With years of international cooperation experience, Dohre CNC Tools has established long-term partnerships with customers worldwide.

We currently have authorized distributors in several countries, including:

•Iran

•Turkey

•Vietnam

Our global partners help deliver high-quality carbide cutting tools and technical support to local markets.

Q1: What is an internal R milling cutter used for?

A1: It is used for machining internal corners with a defined radius, improving part strength and surface finish.

Q2: What is the advantage of corner radius over sharp corners?

A2: Rounded corners reduce stress concentration, improve durability, and enhance surface quality.

Q3: What materials can be machined?

A3: These tools are suitable for:

• • Steel

• • Stainless steel

• • Aluminum

• • Mold materials

Q4: Can you customize the radius size?

A4: Yes, we support full customization of corner radius, tool diameter, and coating based on your requirements.

Q5: How to choose the right corner radius?

A5: The radius depends on the design requirement of your part and machining conditions.

Our engineers can recommend the optimal size based on your application.
